Multiboost
Slimline 200L
Capacity
200L
Pump Options
1 Pump
Speed
Fixed or Variable
Control Options
Easy Press, Presflo Multi, Steadypres
Key Features
- Non-corrosive holding tank (WRAS approved material)
- Pre-fitted fill valve
- Minimal installation requirement
- Adjustable display flow controller (Variable Speed Option only)
- Dry-run protection with auto restart (time delay)
- Equipped with drain off/gravity feed connect option
Description
The Slimline range is designed to fit through a standard doorway, making it ideal for both new builds and retrofit installations.
Its compact form allows it to be easily installed under stairs, in garages or within utility rooms, offering a convenient solution for a variety of property layouts.
The Slimline Range is ideal for 3–5 bedroom homes experiencing poor water pressure and flow, particularly where floor space is limited.
The system is electronically controlled, automatically starting and stopping the pump as outlets are opened and closed – ensuring reliable and efficient performance.
Its compact form allows it to be easily installed under stairs, in garages or within utility rooms, offering a convenient solution for a variety of property layouts.
The Slimline Range is ideal for 3–5 bedroom homes experiencing poor water pressure and flow, particularly where floor space is limited.
The system is electronically controlled, automatically starting and stopping the pump as outlets are opened and closed – ensuring reliable and efficient performance.
Interact with the Multiboost
Model Options
*The Multiboost Range can be found nation wide.
*Please note that we have a policy of continuous product development and specifications may change from those shown.
*Drip tray, insulation jacket and anti-vibration mat available on request
Slimline 200L Fixed Speed
Speed
Fixed Speed
Controller
Easy Press
Size
584 × 1190mm
Weight
26kg
Stock ID
1081646
Slimline 200L Fixed Speed
Speed
Fixed Speed
Controller
Presflo Multi
Size
584 × 1190mm
Weight
26kg
Stock ID
1012150
Slimline 200L Variable Speed
Speed
Variable Speed
Controller
Steadypres
Size
584 × 1190mm
Weight
31kg
Stock ID
1020504
View Model Datasheet
| Stock Code | Model | Control Type | L (mm) | W (mm) | H (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 1081646 | Slimline Simplicity 200L Fixed Speed | Easy Press | - | 584 | 1190 | 26 |
| 1012150 | Slimline 200L Fixed Speed | Presflo Multi | - | 584 | 1190 | 26 |
| 1020504 | Slimline 200L Variable Speed | SteadyPres | - | 584 | 1190 | 31 |
Not sure which one is for you?
Learn more on our pump controller comparison page ->
Technical Details
Pump Details
| Pump Option | kW | HP | A | Pressure | Bar 1 | Bar 2 | Bar 3 | Bar 4 | Bar 5 | Bar 6 |
|---|---|---|---|---|---|---|---|---|---|---|
| Fixed Speed Top Multi II | 0.55 | 0.75 | 3.4 | Q 1/min | 73 | 57 | 40 | 10 | - | - |
| Variable Speed NKM 2/4 6-E | 0.75 | 1 | 6.3 | Q 1/min | 80 | 80 | 80 | 68 | 50 | 14 |
System Connections
| Connection | Size |
|---|---|
| Inlet | 1/2" BSP |
| Outlet | 1" BSP |
| Overflow | 1" BSP |
| Drain Off / Gravity | 1" BSP |
Extra Information
| Power Supply | 240v 50Hz |
|---|---|
| Access Cover | 190mm |
| Tank Weight | 1L = 1 kg plus weight of empty tank |
